Lab use disc stack centrifuge automatic continue workingIntroduction:
Disc separator can complete two operations: liquid-solid separation (low concentration slurry separation), said clarifying operation; liquid-liquid (or liquid-liquid-solid) separation (emulsion separation), said separating operation. Disc separator with its compact, small footprint, high production capacity and other characteristics, is widely used in chemical, pharmaceutical, light industry, food, biological engineering, and transportation.
Competitive Advantages: Application: Disc centrifuge is mainly used in oil, beer, chemical industry, medicine,traditional Chinese medicine, fermentation broth, fruit juice purification and pulp fiber separation, soybean, peanut, wheat and other plant and animal whitening separation, various animal oils, vegetable oil, mineral oil separation, vaccines, dyes, pigments, additives, dairy products, humic acid, etc.Material separation in graphene, sewage treatment and other industries.
Equipment features: 1) Automatic slag discharge type, including partial slag discharge and full slag discharge. 2) Labyrinth sealing mode is adopted, centripetal pump is adopted for discharging, and the outlet pressure is large, which can be directly transported. 3)The self-designed centripetal pump system has the characteristics of stable output pressure, large regulation range and convenient operation. 4) The power transmission adopts hydraulic coupling transmission, with stable operation and no noise and odor pollution. 5) With fully automatic motor protection device (including start-up and normal operation) 6)The light phase outlet adopts on-line pressure regulating structure, and the discharge concentration can be adjusted flexibly and timely according to needs. 7) The control panel adopts color LCD, which is clear and intuitive, and the operation is simple and convenient.
Model | DH5 | DH15 | Bowl speed (rpm) | 7700 | 7320 | Centrifugal force | 10000G
| 9000G | Capacity (L/H) | 50-200L/H | 500-1500L/H | Outline size (L*W*H) | 1000*350*1280 | 800*600*1300 | Weight (kg) | 180 | 500 | Impurity in clarified liquid | ≤2mg/kg, ≤0.2μmm | ≤2mg/kg, ≤0.2μmm | Output mode | centripetal pump | centripetal pump | Inlet pressure (Mpa) | 0.2 | 0.2 | Outlet pressure(Mpa) | 0.4 | 0.4 | Motor power (KW) | 1.5 | 4 |
